Chapter 15: Maintaining Your Library
Maintenance Actions
630
Verification Test Graphical Reports
Some verification tests produce graphical reports that let you easily see
if the test generated passed or failed results. Each result is shown in a
different color:
• P - passed (green)
• F - failed (red)
There are eight types of graphical reports. Each individual test generates
two or more graphical reports (except for the scan barcode test, which
does not generate graphical reports). The following sections show an
example of each type of graphical report and actions to take to correct a
failed result.
To view the graphical reports for a test, click Reports on the
Verification Tests dialog box.
the report window.
Figure 68 on page 631 shows the parts of
