Figure 8 Operator Panel User Interface - Home Screen - Quantum scalar i40 User Manual

Chapter 3: Understanding the User Interface
Operator Panel
Operator Panel Layout
and Functions
Figure 8 Operator Panel User
Interface - Home Screen
Title bar
Active display
Menu bar
Navigation/selection
buttons
22
The operator panel home screen refreshes every 5 seconds to provide
up-to-date information about library performance.
You can choose your desired operator panel home screen that displays
on the local user interface—the default home screen or the alternate
home screen that allows easy I/E unlock access.
depict these screen options;
functions.
Name
You can choose to change the view of the home screen for easy I/E
unlock access. Refer to
page 108.
Table 2 describes the operator panel
Status
Changing Operator Panel Home Screen View
Quantum Scalar i40 and Scalar i80 User's Guide
Figure 8 and Figure 9
Health status
on
