Element Description
Port Index The port number.
Location The location of the port (for example, MCB).
Port Mode The mode of the port (Target or Initiator).
Status The status of the Fibre Channel (Operational, Lost Sync).
WWPN The World Wide Port Name.
Quantum Scalar i6000 User's Guide
you want the I/O blades sorted. Repeatedly clicking a column
heading toggles between ascending and descending order.
• Mail, save, or print status information by using the Send button
(see Mailing, Saving, and Printing Status Information
page 548.
Viewing Fibre Channel Status Information
1 Make sure that you are viewing the physical library. From the View
menu, click the name of the physical library.
2 Click Monitor > Connectivity > Fibre Channel. The Fibre Channel
Status dialog box appears.
The following table describes the elements on the Fibre Channel
Status dialog box.
Chapter 15: Maintaining Your Library
Monitoring the Library
