Chapter 2: Troubleshooting Your Library
Interpreting LEDs
Interpreting Ethernet
Expansion Blade LEDs
Figure 27 Location of Ethernet
Expansion Blade Status LEDs
Table 15 Ethernet Expansion
Blade LED States
Blue Green
Off Off
1 Hz Off
102
The status LEDs for an Ethernet Expansion blade are located at the top
of the EEB above ETH 6.
LEDs.
EEB status LEDs
Ethernet
Port status LEDs
Amber
Off
Off
Figure 27 shows the locations of the EEB status
Description
No power
Powered Down - Ready for removal
