Chapter 15: Maintaining Your Library
Maintenance Actions
624
• Accessor Assembly
• Picker Assembly
• Drive Sled Assembly
• IE Assembly
• Scan Barcode
When one of the sub-tests is selected, you may be prompted to enter
additional information. For example, the Select FRU dialog box has tabs
along the top to select individual drives, I/E stations, and scratch tapes.
Custom Test
The Custom test enables you to run the Library Alignment sub-test on a
per-rack basis.
Sub-test Descriptions
Use the Verification Tests dialog box to select the test and sub-test, to
start the test, and view results.
Verification Tests dialog box. To display the dialog box, click Tools >
Verification Tests.
Figure 67 shows the parts of the
