Chapter 2: Troubleshooting Your Library
Interpreting LEDs
LED On/Off Combinations
1 2 3 4
On Off Off On
On Off Off Off
On Off Off Off
On On Off Off
On On Off On
On On Off On
On On Off On
On On Off Off
On On Off On
On On Off Off
On On Off Off
108
5 6 Explanation
Off On The library has one control module and five expansion modules.
On Off The library has one control module and six expansion modules.
Off On The library has one control module and seven expansion modules.
Off Off The library has one control module and eight expansion modules.
Off Off The library has one control module and nine expansion modules.
On Off The library has one control module and ten expansion modules.
On On The library has one control module and eleven expansion
modules.
On On The library has one control module and twelve expansion
modules.
Off On The library has one control module and thirteen expansion
modules.
On Off The library has one control module and fourteen expansion
modules.
Off On The library has one control module and fifteen expansion
modules.
LBX Terminator Version 2 LEDs
The LBX terminator has six blue LEDs that indicate the presence of
modules in the library.
Table 20 on page 109 describes how to interpret LED activity on the LBX
terminator.
Figure 32 shows the locations of the LEDs.
