Table 32 Example Path List
Addressed Logical
SAN Unit
1 Tape drive 1
1 Library Controller
2 Tape drive 1
2 Library Controller
1 Tape drive 2
1 Library Controller
2 Tape drive 2
2 Library Controller
Quantum Scalar i6000 User's Guide
Example SCSI
Port Address
A ID 1 LUN 0
A ID 1 LUN 1
B ID 2 LUN 0
B ID 2 LUN 1
A ID 3 LUN 0
A ID 3 LUN 1
B ID 4 LUN 0
B ID 4 LUN 1
ACPF Configuration
1 Access the appropriate screen in one of two ways:
• From the SNW Wizard: Select Setup > SNW Wizard. Click Next.
From the Select Storage Networking Option screen, select
Control Path and click Next. See
Wizard on page 358.
• Select Setup > Partitions > Control Path from the main
console.
The Control Path Configuration dialog box appears, displaying all
partitions that contain drives eligible to be a control path.
Chapter 10: Path Failover
Configure Control Path
Example Logical Unit
Worldwide Identifiers
50:01:10:a0:00:00:00:01
50:01:10:a0:00:00:00:02
50:01:10:a0:00:00:00:01
50:01:10:a0:00:00:00:02
50:01:10:a0:00:00:00:03
50:01:10:a0:00:00:00:02
50:01:10:a0:00:00:00:03
50:01:10:a0:00:00:00:02
Use the Storage Networking
