Operator Panel

Figure 19 Operator Panel

Status indicator
Robotics Enabled
indicator/button
Scalar i2000 User's Guide
The operator panel is located on the front of the control module and
consists of indicators and a touch screen (see
for library control and power, and the indicators provide library status.
The touch screen is the library navigation point and provides access to
the LMC. For more information about the touch screen and the LMC, see
Operator Panel and Library Management Console (LMC)
Chapter 3 Description
Operator Panel
figure 19). The buttons are
Power indicator/button
touch screen
on page 349.
100
