Chapter 3: Configuring Your Library
Setting Up the Network Configuration
166
Element Description
In the Host Settings area:
DHCP If Dynamic Host Configuration Protocol (DHCP) is
enabled on your network, do one of the following:
• Select Enable to have DHCP automatically
• Select Disable to make the IP Address, Subnet
Library Name The network name that you want to assign to the
library.
IP Address The IP address of the library. This text box is
available only if DHCP is disabled.
Subnet Mask The subnet mask. This text box is available only if
DHCP is disabled.
Default The IP address of the default gateway for your
Gateway portion of the Ethernet network. This text box is
available only if DHCP is disabled only for Interface
1.
In the Port Settings area:
Auto Negotiate • Select Enable to have the library automatically
• Select Disable to make the Speed options
Speed The port speed (10, 100 or 1000 Mbps). Speed
options are available only if Auto Negotiate is
disabled.
The current port settings are listed in the Current Port Settings
section. For more information, see
Port Settings on page 171.
configure the library network settings. Enable
makes the IP Address, Subnet Mask, and
Default Gateway text boxes unavailable.
Mask, and Default Gateway text boxes
available for you to manually set the library
network settings.
negotiate port speeds. Enable makes the Speed
options unavailable.
available for you to manually set the port speed.
Viewing the Current Network
