Generating The Library Configuration Report - Quantum Scalar i6000 User Manual

Generating the Library Configuration Report

Quantum Scalar i6000 User's Guide
Note: You cannot print reports or save them to a PDF file using
the touch screen.
5 When you are finished working with the Print Preview dialog box,
click Close.
6 To close the Report Criteria dialog box, click Cancel.
Exporting a Report to an E-mail or a Text File
Instead of viewing or printing the report on the Print Preview dialog
box, you can e-mail the report data to an e-mail address. Or export the
report data to a comma delimited text file (*.csv) for use in other
programs.
1 On the menu bar, click Tools > Reports > LUN Mapping. The Report
Criteria dialog box appears.
2 Under Specify Report Criteria, click a grouping option.
• Group by Host — The report lists the devices associated with
each host.
• Group by Partition — The report lists the devices associated
with each partition.
3 Click Export. The Export Raw Data dialog box appears.
4 Do one of the following:
• To send the report data to an e-mail address, click Email. Type or
select the e-mail address, type an optional comment in the
Comment box, and then click OK.
• To save the report data to a comma delimited text file, click
Save. Specify a file path and file name, and then click OK.
5 To close the Report Criteria dialog box, click Cancel.
The Library Configuration report lets you view the number of I/E
stations, drives, and storage slots in the library that are currently
Chapter 3: Configuring Your Library
Generating the Library Configuration Report
225
