Chapter 2: Troubleshooting Your Library
Interpreting LEDs
Figure 24 Rear View of Fibre
Channel Drive Sled (UDS-2)
96
Note: The blinking codes described in
same for Fibre Channel and SCSI drives in the UDS-2 drive sleds.
Figure 24 shows the locations of the status LEDs and the Fibre Channel
link LED on the rear of a UDS-2 drive sled.
fibre port
FC link LED
Figure 25 shows the locations of the status LEDs and the Fibre Channel
link LED on the rear of a UDS-3 drive sled.
Table 10 on page 98 are the
status LEDs:
- top = blue
- middle = amber
- bottom = green
