Guidelines for Start-Up
1.) Parameterization of the basic unit during initial start-up
Choose the method of start-up you require:
1.1) Initial start-up:
a.) Quick parameterization
(QUICK standard start-up in order to quickly "turn" the motor for the first time, for
example, and to test its basic functioning)
See Section 6.3.3.
b.) "Menu-guided start-up" with PC / DriveMonitor
(QUICK standard start-up in order to quickly "turn" the motor for the first time, for
example, and to test its basic functioning)
See DriveMonitor (menu: " Parameters" > submenu:
"Menu-guided start-up")
c.) Detailed parameterization
See Section 6.2
After completing parameterization in accordance with Section 6.2, you can
use the following setting to start the drive immediately and test it:
(precondition: P366 = 0 (STANDARD)):
P554.i1 = 10 ; P555.i1 = 10:
The drive can be switched ON and OFF (coast to stop without electrical
braking torque) by means of terminal –X101 / 3.
P443.i1 = 41; P462.i1 = 3 sec; P464.i1 = 3 sec; (as long as V/f characteristic
has first been selected with P290 = 1: P320.i1 = 75): the setpoint can thus
be specified in % by means of P401.i1 (ramp-up/ramp-down times = 3 sec).
For further parameterization, see the following "Notes on how to proceed further".
Notes on how to proceed further
You should always refer to the function diagrams first (graphic illustration of functions)
before carrying out further parameterization (process data (control values, setpoints and
actual values), functions etc.) or diagnosis.
They can be found in the appendix (Volume 2) of the Compendium.
The function diagrams are subdivided into those for basic functions, free function blocks,
supplementary boards (EBx, SCBx) and the F01 technology option.
Use the list of contents (at the beginning of the function diagrams) to look for functions.
First read the following pages:
♦ Basic functions:
"General":
"Diagnostics":
"Functions":
♦ Free function blocks (if used):
"Sampling times, sampling sequence":
(see also Section 7.1: "Functions / Basic functions")
♦ Control word commands and status word messages:
In addition to the function diagrams (pages [180], [190], [200], [210]), you can find
detailed descriptions of the individual commands /messages in Section 10, "Control Word
and Status Word".
♦ Interfaces (USS, PROFIBUS, SIMOLINK, CAN):
In addition to the function diagrams, you can find detailed descriptions of the interface
functions in Section 8, "Communication".
2
Pages [10], [12], [15], [20], [30]
Pages [510], [515]
Pages [540], [550]
Page [702]
6SE7087-6QX70 (Version AD)
Motion Control Compendium
10.2004
Siemens AG
SIMOVERT MASTERDRIVES
