12.4.7

0x3006/0 Percentage set value

Index Sub-index
0x3006 0
Via object 0x3006 it is possible to write to a percentage source like parameter
erence Value
The value of object 0x3006 is available as source which can be chosen by the selec-
tion of "815 - Obj 0x3006 Reference Percentage" from a parameters choice list.
The value of object 0x3006 is limited to -30000 to 30000 (corresponds to percentage
values -300.00 %...300.00 %).
No.
0x3006/0 Percentage set value
Example: Technology controller parameter
The percentage value is scaled as percent * 100 (e.g. 5678 represents 56.78%).
Example:
Read Request
Reply
Write Access
Reply
CB: Control byte
90
Meaning
Percentage set value
056.
Object
COB ID CB
601 40
581 4B
601 2B
581 60
SI: Sub Index All values in hexadecimal without leading 0x
CM-CAN ACU
Data type
Unsigned16
Min.
-30000
(= 0x8AD0)
S. Reference Value
Index SI Data
06 30 00 00 00
06 30 00 05 00
06 30 00 20 00
06 30 00 00 00
Access Map Def.-Val
rw Rx 0
S. Ref-
Max.
30000
(= 0x7530)
056.
04/13
