Warning Messages Application - BONFIGLIOLI Vectron Active Cube User Manual

16.4

Warning Messages Application

When the highest bit in the Warning messages is set, a "Warning Message Application" is present.
The Application warning messages are given via parameter
according to the following scheme.
Parameter
Application Warnings
the PC software tool VPlus.
Use Parameter
Application Warnings
Bit-No. Bit-No.
0 0x0001
1 0x0002
2 0x0004
3 0x0008
4 0x0010
5 0x0020
6 0x0040
7 0x0080
8 0x0100
9 0x0200
10 0x0400
11 0x0800
12 0x1000
13 0x2000
14 0x4000
15 0x8000
The warnings are described in detail in the operating instructions or the application
manual "Positioning" respectively.
The Warning Bit 6 "Absolute encoder" can be read out via Parameter 1274 in VPlus or
1273 via field bus. The Absolute encoder warnings are described in detail in the Exten-
sion manual EM-ABS-01.
230
273 shows the warnings in clear text on the operator panel and
274 to access the Application warning codes via Field bus.
Warning Messages
BELT - Keilriemen
SW-LIM CW – SW limit switch Clockwise
SW-LIM CCW – SW limit switch Counterclockwise
HW-LIM CW – HW limit switch Clockwise
HW-LIM CCW – HW limit switch Counterclockwise
CONT – Contouring error
ENC – Warning Absolute encoder
User 1 – User Warning 1
User 2 – User Warning 2
(reserviert)
(reserviert)
(reserviert)
(reserviert)
(reserviert)
(reserviert)
(reserviert)
CM-CAN ACU
Application Warnings
Bit-No.
274, bit-coded
04/13
