The special function generator is only evaluated, if 1299
is set unequal to "9 –Zero".
tor
If 1299
put is always used.
If Special function generator 1299
"9-Zero", the reference value from the ramp output is also used when Bit 4 "rfg ena-
ble" = 1 and when Bit 4 "rfg enable" = 0 the reference value is used from the source
set in 1299
Bit 4 rfg enable = 0
Bit 4 rfg enable = 1
Bit 5:rfg unlock
Rfg unlock = 0 The last speed value is hold and used.
Rfg unlock = 1 The ramp function is active and will change the speed according to the
setpoint and the ramp.
Bit 6: rfg use ref
Rfg use ref = 0 The setpoint "0" is used.
Rfg use ref = 1 The setpoint of
Bit 8: Halt
HALT = 0
HALT = 1
