10 Operational behavior on bus failure

The operational behavior if the CANopen
heartbeat, SYNC error, RxPDO length error or NMT state change (leaving NMT state
operational) can be parameterized. The required behavior is set with parameter
Error Behavior
For the description of the inverter's functional behavior, see chapter 12.5.1 "0x6007/0
Abort Connection option code".
CAN Error Behavior
0 - No Reaction
1 - Error
2 - Switch-off
3 - Quick-Stop
4 - Ramp-Stop + Error
5 - Quick-Stop + Error
NOTE
The parameter settings
of parameter
"0x6007/0 Abort Connection option code".
Parameter
0x6007 abort connection option
The error and warning behavior of the frequency inverter can be parameterized in
various ways. Occurring errors are described in detail in chapter 16.5 "Fault messag-
es".
NOTE
The disconnection of a connector or another contact loss can only be detected safe-
ly via set up timeout monitoring.
