12.4.6

0x3005/0 Boolean DeMux

Index Sub-index
0x3005 0
Via object 0x3005 up to 16 boolean values can be written in a compressed manner.
These values are available as sources which can be chosen by the selection of
832 ... 847
Bit no.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Example:
Read Request
Reply
Write Access
Reply
CB: Control byte
04/13
Meaning
Boolean DeMux
Obj 0x3005 Demux Out 1...16
Source No.
832
833
834
835
836
837
838
839
840
841
842
843
844
845
846
847
COB ID CB
601 40
581 4B
601 2B
581 60
SI: Sub Index All values in hexadecimal without leading 0x
CM-CAN ACU
Data type
Unsigned16
from a parameters choice list.
Obj. 0x3005
Source name
Obj. 0x3005 Demux Out 1
Obj. 0x3005 Demux Out 2
Obj. 0x3005 Demux Out 3
Obj. 0x3005 Demux Out 4
Obj. 0x3005 Demux Out 5
Obj. 0x3005 Demux Out 6
Obj. 0x3005 Demux Out 7
Obj. 0x3005 Demux Out 8
Obj. 0x3005 Demux Out 9
Obj. 0x3005 Demux Out 10
Obj. 0x3005 Demux Out 11
Obj. 0x3005 Demux Out 12
Obj. 0x3005 Demux Out 13
Obj. 0x3005 Demux Out 14
Obj. 0x3005 Demux Out 15
Obj. 0x3005 Demux Out 16
Index SI Data
05 30 00 00 00
05 30 00 05 00
05 30 00 20 00
05 30 00 00 00
Access Map Def.-Val
rw Rx 0
89
