1E – 34 ENGINE ELECTRICAL
4–7 NSm
4–6 NSm
D Tighten the through-bolts to 4–6 NSm (35–53 lb-in)
(f).
D Tighten the battery positive terminal nut to 4–7
NSm (35–62 lb-in) (g).
D12E760A

DISTRIBUTOR ASSEMBLY

Disassembly Procedure
1. Remove the distributor. Refer to "Distributor" in this
section.
2. Remove the cap, seal and rotor from the distributor
housing.
D Remove the bolts (1).
D Remove the distributor cap (2).
D Remove the seal (3).
D Remove the rotor (4).
D102E761
D Inspect the cap for cracks or damage (a).
D Inspect the cap electrode for damage / wear or car-
bon traces (b).
D Inspect the rotor for damage or carbon traces (c).
D102E762
3. Remove the inner / outer cover from the distributor
housing.
D Remove the outer cover (1).
D Remove the screws (2).
D Remove the inner cover (3).
D102E763
DAEWOO M-150 BL2
