Daewoo MATIZ Service Manual page 145

Step
Measure the voltage between the CKP sensor
connector terminal 2 and ground.
21
Is the voltage within the value specified?
Check the wire between the CKP sensor connector
terminal 2 and the ECM connector terminal 24 for an
22
open or short.
Is the problem found?
Repair the wire between the CKP sensor connector
terminal 2 and the ECM connector terminal 24.
23
Is the repair complete?
1. Turn the ignition OFF.
2. Connect a test light between the EI system
ignition coil connector terminal 2 and ground.
24
3. Turn the ignition ON.
Is the test light on?
Check for an open in the wiring between the EI
system ignition coil connector, terminal 1 and the
25
main relay connector terminal 87.
Is the problem found?
Repair the open in the wiring between the EI system
ignition coil connector terminal 1 and the main relay
26
connector terminal 87.
Is the repair complete?
Check for a damage in the terminal of the EI system
ignition coil connector and repair as needed.
27
Is the repair complete?
DAEWOO M-150 BL2
Ignition System Check (Cont'd)
Action
ENGINE CONTROLS 1F – 47
Value(s) Yes
0.95–1.10 V Go to Step 18
–
Go to Step 23
–
System OK
–
Go to Step 27
–
Go to Step 26
–
System OK
–
System OK
No
Go to Step 22
Go to Step 11
–
Go to Step 25
Go to "Main
Relay Circuit
Check"
–
–
