1F – 46 ENGINE CONTROLS
Step
Check for an open in the wire from EI system
ignition coil connector terminal 2 to the Engine
9
Control Module (ECM) connector terminal 1.
Is the problem found?
1. Replace the EI system ignition coil.
2. Connect the EI system ignition coil connector.
10
3. Check for the presence of spark from all of the
ignition wires.
Is spark present from all of the ignition wires?
1. Replace the ECM.
2. Connect the EI system ignition coil connector.
11
3. Check for the presence of spark from all of the
ignition wires.
Is spark present from all of the ignition wires?
1. Turn the ignition OFF.
2. Disconnect the crankshaft position (CKP) sensor
connector.
3. Measure the resistance between the CKP sensor
terminals 1 and 2.
Is the resistance within the value specified?
12
4. Measure the resistance between following
terminals.
D Terminals 1 and 3 of CKP sensor.
D Terminals 2 and 3 of CKP sensor.
Is the resistance within the value specified?
Replace the crankshaft position sensor.
13
Is the repair complete?
1. Turn the ignition ON.
2. Measure the voltage between the CKP sensor
14
connector terminals 1 and 3.
Is the voltage within the value specified?
Measure the voltage between the CKP sensor
connector terminal 1 and ground.
15
Is the voltage within the value specified?
Check the wire between the CKP sensor connector
terminal 1 and the ECM connector terminal 54 for an
16
open or short.
Is the problem found?
Repair the wire between the CKP sensor connector
terminal 1 and the ECM connector terminal 54.
17
Is the repair complete?
Check the wire between the CKP sensor connector
terminal 3 and ground for an open or short.
18
Is the problem found?
Repair the wire between the CKP sensor connector
terminal 3 and ground.
19
Is the repair complete?
1. Turn the ignition ON.
2. Measure the voltage between the CKP sensor
20
connector terminals 2 and 3.
Is the voltage within the value specified?
Ignition System Check (Cont'd)
Action
Value(s)
Yes
Go to Step 7
System OK
System OK
400–600 Ω
Go to Step 14
System OK
0.95–1.10 V
Go to Step 20
0.95–1.10 V
Go to Step 18
Go to Step 17
System OK
Go to Step 19
System OK
0.95–1.10 V
Go to Step 24
No
Go to Step 11
Go to Step 13
Go to Step 15
Go to Step 16
Go to Step 10
Go to Step 11
Go to Step 21
