Daewoo MATIZ Service Manual page 89

9–12 NSm
9–12 NSm
DAEWOO M-150 BL2
D12E756A
D12E757A
D12E758A
80–110 NSm
D12E759A
ENGINE ELECTRICAL 1E – 33
5. Inspect the brush wear
D If the brush wear exceeds the specified value, re-
place the brush.
a. Brush wear limit.
Desciption Standard
Brushes wear 20 (0.79)
Assembly Procedure
1. Install in the reverse order of removal.
2. Install the screws / nuts / bolts.
Tighten
D Tighten the regulator screw to 9–12 NSm (80–106
lb-in) (a).
D Tighten the rectifier / regulator screw to 9–12 NSm
(80–106 lb-in) (b).
D Tighten the brush holder / regulator screw to 9–12
NSm (80–106 lb-in) (c).
D Tighten the rectifier bolts to 9–12 NSm (80–106 lb-
in) (d).
D Tighten the pulley nut to 80-110 NSm (59–81 lb-ft)
(e).
Limit
14 (0.55)
