Dtc P0133: O2 Sensor (Ho2S) Circuit Slow Response (Sensor-1) - Suzuki Swift Sport 2004 Service & Repair Manual

DTC P0133: O2 Sensor (HO2S) Circuit Slow Response (Sensor-1)

DTC Detecting Condition and Trouble Area
Response time (time to change from lean to rich or from rich to lean) of HO2S-1 output
voltage is about 1 sec. at minimum or average time of 1 cycle is 5 sec. at minimum.
(*2 driving cycle detection logic, monitoring once per driving cycle)
DTC Confirmation Procedure
WARNING
!
• When performing a road test, select a place where there is no traffic or possibility of a traffic
accident and be very careful during testing to avoid occurrence of an accident.
• Road test should be carried out by 2 persons, a driver and a tester, on a level road.
NOTE
Check to make sure that following conditions are satisfied when using this "DTC Confirmation
Procedure".
• Intake air temperature at engine start: –10 °C (14 °F) to 80 °C (176 °F)
• Intake air temperature: –10 °C (14 °F) to 70 °C (158 °F)
• Engine coolant temperature: 70 °C (158 °F) to 150 °C (302 °F)
• Altitude (barometric pressure): 2400 m, 8000 ft or less (560 mmHg, 75 kPa or more)
1) With ignition switch turned OFF, connect scan tool.
2) Turn ON ignition switch and clear DTC using scan tool.
3) Start engine and warm up to normal operating temperature.
4) Drive vehicle at 40 mph (60 km/h) or higher. (engine speed: 2500 – 3000 r/min.)
5) Keep above vehicle speed for 6 min. or more. (Throttle valve opening is kept constant in this step.)
6) Release accelerator pedal and with engine brake applied, keep vehicle coasting (with fuel cut for 3 sec. or more)
and then stop vehicle.
7) Check if DTC and pending DTC exist by using scan tool. If not, check if oxygen sensor monitoring test has been
completed by using scan tool. If not in both of above checks (i.e., no DTC and pending DTC and oxygen sensor
monitoring test not completed), check vehicle condition (environmental) and repeat Step 3) through 6).
DTC Troubleshooting
NOTE
• When measuring circuit voltage, resistance and/or pulse signal at ECM connector, connect the
special tool to ECM and/or the ECM connectors referring to "Inspection of ECM and Its Circuits".
• Upon completion of inspection and repair work, perform "DTC Confirmation Procedure" and
confirm that the trouble has been corrected.
Step
1 Was "Engine and Emission Control System Check"
performed?
2 Is there DTC(s) other than HO2S-1 (DTC P0133)?
DTC detecting condition
Action
Engine General Information and Diagnosis:
Yes
Go to Step 2.
Go to applicable DTC
diag. flow.
1A-91
S7RS0B1104032
Trouble area
Heated oxygen sensor-1
No
Go to "Engine and
Emission Control
System Check".
Replace HO2S-1.
