Supporting the collaboration function
Collaboration is implemented by establishing collaboration entries to monitor the
detection results of the current test group. If the number of consecutive probe
failures reaches a certain limit, NQA's collaboration with other modules is
triggered. The implementation of collaboration is shown in Figure 596.
Figure 596 Implementation of collaboration
Application modules
VRRP
VRRP
Static routing
Static routing
Policy routing
Policy routing
Backup center
Backup center
The collaboration here involves three parts: the application modules, the Track
module, and the detection modules.
The detection modules monitor the link status, network performance and so
■
on, and inform the Track module of the detection result.
Upon receiving the detection result, the Track module changes the status of the
■
Track object accordingly and informs the application modules. The Track
module works between the application modules and the detection modules
and is mainly used to obscure the difference of various detection modules to
provide a unified interface for application modules.
The application modules then deal with the changes accordingly based on the
■
status of the Track object, and thus collaboration is implemented.
Take static routing as an example. You have configured a static route with the next
hop 192.168.0.88. If 192.168.0.88 is reachable, the static route is valid; if
192.168.0.88 is unreachable, the static route is invalid. With the collaboration
between NQA, Track module and application modules, real time monitoring of
reachability of the static route can be implemented:
1 Monitor reachability of the destination 192.168.0.88 through NQA.
2 If detecting 192.168.0.88 is unreachable, NQA will inform the static routing
module through Track module.
3 The static routing module then can know that the static route is invalid.
For the detailed description of the Track module, refer to "Track Configuration" on
page 2207.
Supporting delivery of traps
You can set a switch to control the delivery of traps to the network management
server.
