EAP Encapsulation over
RADIUS
Figure 501 EAP packet format
0 7
Code
Length
Data
Code: Type of the EAP packet, which can be Request, Response, Success, or
■
Failure.
An EAP packet of the type of Success or Failure has no Data field, and has a length
of 4.
An EAP packet of the type of Request or Response has a Data field in the format
shown in Figure 502. The Type field indicates the EAP authentication type. A value
of 1 represents Identity, indicating that the packet is for querying the identity of
the supplicant. A value of 4 represents MD5-Challenge, which corresponds closely
to the PPP CHAP protocol.
Figure 502 Format of the Data field in an EAP request/response packet
0 7
Type
Identifier: Allows matching of responses with requests.
■
Length: Length of the EAP packet, including the Code, Identifier, Length, and
■
Data fields, in bytes.
Data: Content of the EAP packet. This field is zero or more bytes and its format
■
is determined by the Code field.
Two attributes of RADIUS are intended for supporting EAP authentication:
EAP-Message and Message-Authenticator. For information about RADIUS packet
format, refer to "AAA/RADIUS/HWTACACS Configuration" on page
EAP-Message
The EAP-Message attribute is used to encapsulate EAP packets.
its encapsulation format. The value of the Type field is 79. The String field can be
up to 253 bytes. If the EAP packet is longer than 253 bytes, it can be fragmented
and encapsulated into multiple EAP-Message attributes.
Figure 503 Encapsulation format of the EAP-Message attribute
0 7
Type
15
Identifier
2
4
N
N
Type data
15
Length String
EAP packets
802.1x Overview 1733
1751.
Figure 503 shows
