Configuring A Calling Number Permitted To Call In; Configuration Task List - 3Com MSR 50 Series Configuration Manual

Configuration Task
List
Configuring a Calling
Number Permitted to
Call In
If there exist multiple number substitution rules in a number substitution rule list,
only one number substitution rule will be matched. The match process is as
follows:
1 The preferred number substitution rule is matched first. If the match succeeds, the
gateway substitutes numbers on basis of this rule.
2 If the match fails, the gateway matches other number substitution rules in
sequence. Once a rule is matched successfully, the gateway stops matching other
number substitution rules.
n
Here, the dot represents virtually matched digits. Virtually matched digits,
including ., +, %, !, and [], refer to those that match the variable part in an
regular expression. For example, the virtually matched digits are the digit "2", the
digit "5", and the digits "25" respectively when the number 1255 matches the
regular expressions 1[234]55, 125+, and 1..5.
Complete these tasks to complete a dial plan.
Task
"Configuring a Calling Number Permitted to Call In" on
page 2293
"Enabling Private Line Auto Ring-Down" on page 2294
"Configuring a Number Match Mode" on page 2294
"Configuring Voice Entity Selection Priority Rules" on page
2295
"Configuring a Number Priority Peer" on page 2296
"Configuring a Maximum-Call-Connection Set" on page
2297
"Configuring Number Substitution" on page 2298
"Configuring Number Sending Mode" on page 2300
"Configuring a Dial Prefix" on page 2301
Follow these steps to configure a calling number permitted to call in:
To do...
Enter system view
Enter voice view
Enter voice dial program view dial-program
Create a voice entity and
enter voice entity view
Configure a calling number
permitted to call in
n
The calling-string argument is in the format of { [ + ] string [ $ ] }| $. For specific
meanings of these symbols in the format, refer to Dial Plan Commands in Voice
Volume.
Use the command...
system-view
voice-setup
entity entity-number { pots |
vofr | voip }
caller-permit calling-string

Configuration Task List

Remarks
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Remarks
-
-
-
-
Optional
By default, no calling number
is configured, that is,
incoming calls are not
restricted.
2293
