Configuring
Asynchronous Serial
Interface Attributes
Configuring Terminal
Attributes
Task
"Configuring the auto-execute Command" on page 2159
"Configuring User Privilege Level" on page 2159
"Configuring Access Restriction on VTY User Interface(s)" on page
2160
"Configuring Supported Protocols on VTY User Interface(s)" on page
2160
"Configuring Redirection Function on Asynchronous Serial Interface(s)"
on page 2161
"Configuring Authentication Mode at Login" on page 2162
"Defining Shortcut Keys for Starting Terminal Sessions/Aborting Tasks"
on page 2164
"Sending Messages to the Specified User Interface(s)" on page 2164
"Releasing the Connection Established on the User Interface(s)" on
page 2164
Follow these steps to configure asynchronous attributes of a serial interface:
To do...
Enter system view
Enter user interface
view
Configure transmission
speed
Configure flow control
mode
Set parity bits
Set stop bits
Detect stop bits
Set data bits
To do...
Enter system view
Enter user interface view

Configuring Asynchronous Serial Interface Attributes

Use the command...
system-view
user-interface { first-num1
[ last-num1 ] | { aux | console |
tty | vty } first-num2
[ last-num2 ] }
speed speed-value
flow-control { { hardware
[ flow-control-type1 ] |
software
[ flow-control-type2 ] } * |
none }
parity { even | mark | none |
odd | space }
stopbits { 1 | 1.5 | 2 }
stopbit-error intolerance
databits { 5 | 6 | 7 | 8 }
Use the command...
system-view
user-interface { first-num1
[ last-num1 ] | { aux | console
| tty | vty } first-num2
[ last-num2 ] }
Remarks
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Remarks
--
--
Optional
9600 bps by default
Optional
The default settings and support
for the flow-control-type1 and
flow-control-type2 arguments vary
with devices.
Optional
None by default
Optional
1 by default
Optional
By default, stop bits are not
detected.
Optional
8 by default
Remarks
--
--
