730 C 49: T
HAPTER UNNELING
Displaying and
Maintaining Tunneling
Configuration
Troubleshooting
Tunneling
Configuration
C
ONFIGURATION
[RouterA] ping ipv6 2002:3::1
PING 2002:3::1 : 56
Reply from 2002:3::1
bytes=56 Sequence=1 hop limit=64
Reply from 2002:3::1
bytes=56 Sequence=2 hop limit=64
Reply from 2002:3::1
bytes=56 Sequence=3 hop limit=64
Reply from 2002:3::1
bytes=56 Sequence=4 hop limit=64
Reply from 2002:3::1
bytes=56 Sequence=5 hop limit=64
--- 2002:3::1 ping statistics ---
5 packet(s) transmitted
5 packet(s) received
0.00% packet loss
round-trip min/avg/max = 1/19/31 ms
To do...
Display information related to
a specified tunnel interface
Display IPv6 information
related to a specified tunnel
interface
n
For details about BGP, refer to
Symptom: After the configuration of related parameters such as tunnel source
address, tunnel destination address, and tunnel type, the tunnel interface is still
not up.
Solution: Follow the steps below:
1 The common cause is that the physical interface of the tunnel source is not up.
Use the display interface tunnel or display ipv6 interface tunnel commands
to view whether the physical interface of the tunnel source is up or down. If the
physical interface is down, use the debugging tunnel event command in user
view to view the cause.
2 Another possible cause is that the tunnel destination is unreachable. Use the
display ipv6 routing-table or display ip routing-table command to view
whether the tunnel destination is reachable. If no routing entry is available for
tunnel communication in the routing table, configure related routes.
data bytes, press CTRL_C to break
time = 31 ms
time = 1 ms
time = 16 ms
time = 16 ms
time = 31 ms
Use the command...
display interface tunnel
[ number ]
display ipv6 interface
tunnel number
"BGP Configuration" on page
Remarks
Available in any view
Available in any view
825.
