Configuring the DVPN
Tunnel Parameters

Prerequisites

Configuring a DVPN
Tunnel
To do...
Configure the PFS (perfect
forward secrecy) setting for
security policy negotiation
Set the duration of security
associations
n
An IPSec profile depends on IKE for SA negotiation. An IPSec profile can
■
reference up to six security proposals. IKE searches for security proposals that
match at both ends during negotiation. If no match is found, SAs cannot be
established and the packets requiring IPSec protection will be discarded.
When IKE uses a security policy to initiate a negotiation, if the local end uses
■
PFS, the remote end must also use PFS for negotiation and both ends must use
the same Diffie-Hellman (DH) group; otherwise, the negotiation will fail.
A security proposal for an IPSec profile to reference must be configured to use
■
the ESP protocol.
An IPSec profile is used specially to protect DVPN traffic. Due to the dynamics
■
of DVPN addresses, the setting by the remote-address keyword for the IKE
peer that an IPSec profile references does not take effect on the initiator.
By configuring this task, you can bind a VAM client to an end of the DVPN tunnel,
the tunnel's idle interval, and dumb interval after a tunnel establishment failure.
You need to specify on the device an IP address for the VLAN interface, Ethernet
interface or Loopback interface, which will act as the source interface of the
tunnel virtual interface, to ensure the destination of the tunnel is reachable.
Follow these steps to configure a DVPN tunnel:
To do...
Enter system view
Create a tunnel interface and
enter its view
Specify an IP address for the
tunnel interface
Specify the DVPN tunnel
mode

Configuring the DVPN Tunnel Parameters

Use the command...
pfs { dh-group1 | dh-group2
| dh-group5 | dh-group14 }
sa duration { time-based
seconds | traffic-based
kilobytes }
Use the command...
system-view
interface tunnel
interface-number
ip address ip-address
net-mask
tunnel-protocol dvpn udp
1569
Remarks
Optional
By default, the PFS setting is
not used in security policy
negotiation.
Refer to "PFS" on page 1902
for information about PFS.
Optional
By default, the time-based
duration of a security
association is 3,600 seconds;
the traffic-based duration is
1,843,200 bytes.
Remarks
-
Required
No tunnel interface is created
by default.
Required
Not specified by default
Required
GRE tunnel mode by default
The two ends of the tunnel
must have the same tunnel
mode.
