Configuring the Time
Adjustment Function
To do...
Enter E1/T1 interface view
Create a TS set for digital
E&M signaling and select a
start mode
Exit E1/T1 interface view
Enter voice view
Enter digital E&M voice
subscriber line view
Configure the ABCD bit
pattern of receive idle signal
Configure the ABCD bit
pattern of receive seized
signal
Configure the ABCD bit
pattern of transit idle signal
Configure the ABCD bit
pattern of transmit seized
signal
The ABCD bit pattern of the receive idle signal from the local end must be the
■
same as that of the transmit idle signal from the remote end. Seized signals
and idle signals are processed in the same way.
After you change the ABCD bit pattern of a digital E&M signal, you need to
■
shut down the digital E&M voice subscriber line with the shutdown command
and then bring the line up with the undo shutdown command. Otherwise,
the voice subscriber line cannot work normally.
Follow these steps to configure the time adjustment function:
To do...
Enter system view
Enter E1/T1 interface view
Create a TS set for digital
E&M signaling and select a
start mode
Exit E1/T1 interface view
Enter voice view
Enter digital E&M voice
subscriber line view
Configure the maximum
interval between any two
digits of a dialed number
Configure the maximum time
the calling party waits for a
ringback response
Configure the maximum time
the called party waits for the
first digit
Configuring Digital E&M Signaling
Use the command...
controller { e1 | t1 } number
timeslot-set ts-set-number
timeslot-list timeslots-list signal
{ e&m-delay | e&m-immediate
| e&m-wink }
quit
voice-setup
subscriber-line
slot-number:ts-set-number
signal-value received idle
ABCD
signal-value received seize
ABCD
signal-value transmit idle
ABCD
signal-value transmit seize
ABCD
Use the command...
system-view
controller { e1 | t1 } number
timeslot-set ts-set-number
timeslot-list timeslots-list signal
{ e&m-delay | e&m-immediate
| e&m-wink }
quit
voice-setup
subscriber-line
slot-number:ts-set-number
timer dial-interval seconds
timer ring-back seconds
timer wait-digit { seconds |
infinity }
2333
Remarks
-
Required
-
-
-
Optional
1101 by default.
Optional
0101 by default.
Optional
1101 by default.
Optional
0101 by default.
Remarks
-
-
Required
-
-
-
Optional
10 seconds by default.
Optional
60 seconds by default.
Optional
5 seconds by default.
