Resetting A Voice Card; Configuring Global Default Voice Parameters - 3Com MSR 50 Series Configuration Manual

2276 C 132: V
HAPTER OICE

Resetting a Voice Card

Configuring Global
Default Voice
Parameters
E C
NTITY ONFIGURATION
To do...
Enter system view
Enter voice view
Set the duration of
monitoring DSP buffered data
Set the DSCP subfield in the
ToS field in the IP packets that
carry the RTP stream or voice
signaling
Configure the time for
switching from VoIP entity to
backup POTS entity in case of
a VoIP call failure
n
In voice view, the vqa dscp media command has global significance, and the
dscp media command is valid only for the configured voice entity..
When a card is reset, all traffic carried by it will be interrupted and the card will be
re-initiated. As a general rule, you can reset a voice card when it works abnormally
(for example, the configuration is correct but the call connection cannot be
established normally). You can observe the status of the LED on the card to judge
whether a reset is performed.
Table 79 Follow these steps to reset a card:
To do...
Enter system view
Enter voice view
Reset the voice card
For each voice entity, if the certain command is not performed to configure a
parameter, the system uses the default value of the parameter.
When there are too many voice entities on one router and the values of most voice
entity parameters are the same as the default values, the default values can be
adopted to improve the efficiency.
In some cases when the manually configured parameter values of most voice
entities are almost the same but different from the default values, to specify
suitable voice parameters for these voice entities one by one will waste much time.
In this case, you can use the default command to generate new default values
globally. In this way, each voice entity will directly inherit new default values, a
more flexible, simple and convenient configuration is thus realized.
Use the command...
system-view
voice-setup
vqa dsp-monitor
buffer-time time
vqa dscp { media | signal }
dscp-value
voip timer voip-to-pots
time
Use the command...
system-view
voice-setup
vi-card reboot slot-number
Remarks
-
-
Optional
By default, DSP buffered data
is not monitored.
Duration greater than 240
milliseconds is recommended
because too small a duration
value will result in poor voice
quality in the case of severe
jitter.
Optional
101110 by default.
Optional
5 seconds by default.
Remarks
-
-
Optional
