User Interface
Overview

Brief Introduction

U I
SER NTERFACE
When configuring user interface, go to these sections for information you are
interested in:
"User Interface Overview" on page 2155
■
"Configuring Asynchronous Serial Interface Attributes" on page 2157
■
"Configuring Terminal Attributes" on page 2157
■
"Configuring Modem Attributes" on page 2158
■
"Configuring the auto-execute Command" on page 2159
■
"Configuring User Privilege Level" on page 2159
■
"Configuring Access Restriction on VTY User Interface(s)" on page 2160
■
"Configuring Supported Protocols on VTY User Interface(s)" on page 2160
■
"Configuring Redirection Function on Asynchronous Serial Interface(s)" on
■
page 2161
"Configuring Authentication Mode at Login" on page 2162
■
"Defining Shortcut Keys for Starting Terminal Sessions/Aborting Tasks" on
■
page 2164
"Sending Messages to the Specified User Interface(s)" on page 2164
■
"Releasing the Connection Established on the User Interface(s)" on page 2164
■
"Displaying and Maintaining User Interface(s)" on page 2164
■
User interface view is a feature that allows you to manage asynchronous serial
interfaces that work in flow mode. By operating under user interface view, you
can centralize the management of various configurations.
At present, the system supports the following four configuration modes:
Local configuration via the Console port
■
Local/Remote configuration via the AUX port (Auxiliary port)
■
Local/Remote configuration via the serial port working in asynchronous mode
■
(TTY)
Local/Remote configuration through Telnet or SSH
■
The four modes correspond to four types of user interfaces. They are:
