Configuring Frame Relay
Queuing Management
R Q S C
ELAY O ONFIGURATION
To do...
Configure a Configure an
DE rule list interface-based DE rule
list
Configure a IP
protocol-based DE rule
list
Enter synchronous interface view
Apply the DE rule list on a Frame Relay
PVC
n
A router can support up to 10 DE rule lists, and each of them can contain up to
100 DE rules.

Configuring Frame Relay queuing management

After the Frame Relay traffic shaping is enabled on a Frame Relay interface, each
PVC under this interface will own its independent PVC queue.
Follow these steps to configure Frame Relay queuing management
To do...
Enter system view
Enter Frame Relay class view
Set the FIFO queue length of
a Frame Relay PVC
Set the queue type of a Frame
Relay PVC to PQ
Set the queue type of a Frame
Relay PVC to CQ
Set the queue type of a Frame
Relay PVC to WFQ
Set the queue type of a Frame
Relay PVC to CBQ
Set the queue type of a Frame
Relay PVC to RTPQ
n
By default, the queuing type of Frame Relay PVC is FIFO.
■
When the congestion management is enabled on Frame Relay PVCs, the queue
■
type on the interface can only be FIFO.
For configurations of PQ, CQ, WFQ, CBQ and RTPQ, refer to
■
Management" on page 1649
Use the command...
fr del list-number
inbound-interface
interface-type
interface-number
fr del list-number
protocol ip [ acl
acl-number | fragments |
greater-than bytes |
less-than bytes | tcp
ports | udp ports ]
interface interface-type
interface-number
fr de del list-number dlci
dlci-number
Use the command...
system-view
fr class class-name
fifo queue-length queue-length
pq pql pql-index
cq cql cql-index
wfq [ congestive-discard-threshold
[ dynamic-queues ] ]
apply policy policy-name outbound
rtpq start-port min-dest-port
end-port max-dest-port bandwidth
bandwidth
for details.
Remarks
Required
Use either command.
By default, no DE rule list
is created.
-
Required
By default, no DE rule list
is applied to FR PVC.
Remarks
-
-
Optional
The value is 40 by
default.
Optional
Optional
Optional
Optional
Optional
"Congestion
