2184 C 123: P E C
HAPTER O ONFIGURATION
Network diagram
Figure 638 Network diagram for PoE
GE 3/1
GE5/1
GE3/2 GE 5/1
Configuration procedure
# Enable PoE for the PSE.
<Sysname> system-view
[Sysname] poe enable pse 4
[Sysname] poe enable pse 6
# Set the maximum power of PSE 4 to 400 watts. You do not need to configure
the power for the card in slot 5 because the default power is configured for it.
[Sysname] poe max-power 400 pse 4
# Enable PoE on GigabitEthernet3/1, GigabitEthernet3/2, GigabitEthernet5/1, and
GigabitEthernet5/2.
<Sysname> system-view
[Sysname] interface gigabitethernet 3/1
[Sysname-GigabitEthernet3/1] poe enable
[Sysname-GigabitEthernet3/1] quit
[Sysname] interface gigabitethernet 3/2
[Sysname-GigabitEthernet3/2] poe enable
[Sysname-GigabitEthernet3/2] quit
[Sysname] interface gigabitethernet 5/1
[Sysname-GigabitEthernet5/1] poe enable
[Sysname-GigabitEthernet5/1] quit
[Sysname] interface gigabitethernet 5/2
[Sysname-GigabitEthernet5/2] poe enable
[Sysname-GigabitEthernet5/2] quit
# Set the power priority level of GigabitEthernet3/2 to critical.
<Sysname> system view
[Sysname] interface gigabitethernet 3/2
[Sysname-GigabitEthernet3/2] poe priority critical
[Sysname-GigabitEthernet3/2] quit
# Set the maximum power of GigabitEthernet5/1 to 9,000 milliwatts.
[Sysname] interface gigabitethernet 5/1
[Sysname-GigabitEthernet5/1] poe max-power 9000
