2334 C 134: E1
HAPTER AND
Querying the Trunk
Circuits of a Timeslot or
a Range of Timeslots
Configuring Digital
LGS Signaling
Configuring the Time
Adjustment Function
Querying the Trunk
Circuits of a Timeslot or
a Range of Timeslots
T1 C
ONFIGURATION
Follow these steps to query the trunk circuits of a timeslot or a range of timeslots:
To do...
Enter system view
Enter E1/T1 interface view
Create a TS set for digital
E&M signaling and select a
start mode
Enter digital E&M signaling
view
Query the trunk circuits of a
timeslot or a range of
timeslots
Follow these steps to configure the time adjustment function:
To do...
Enter system view
Enter E1/T1 interface view
Create a TS set, enable digital
LGS signaling and set its start
mode
Enter voice view
Enter voice subscriber line
view
Configure the dial delay
Configure the maximum time
waiting for the subscriber to
dial the first digit
Configure the maximum
interval between any two
dialed digits
Configure the maximum time
that the calling party waits for
a ringback response
n
For the delay start-dial, timer first-dial, timer dial-interval, delay, delay
send-dtmf, and timer ring-back commands, refer to
2243.
Follow these steps to query the trunk circuits of a timeslot or a range of timeslots:
To do...
Enter system view
Use the command...
system-view
controller { e1 | t1 } number
timeslot-set ts-set-number
timeslot-list timeslots-list signal
{ e&m-delay | e&m-immediate |
e&m-wink }
cas ts-set-number
ts query timeslots timeslots-list
Use the command...
system-view
controller { e1 | t1 } number
timeslot-set ts-set-number
timeslot-list timeslots-list
signal { fxo-ground |
fxs-ground | fxo-loop |
fxs-ground | fxs-loop }
voice-setup
subscriber-line:
ts-set-number
delay start-dial value
timer first-dial seconds
timer dial-interval seconds
timer ring-back seconds
Use the command...
system-view
Remarks
-
-
Required
-
Optional
Remarks
-
-
Optional
-
-
Optional
1 second by default.
Optional
10 seconds by default.
Optional
10 seconds by default.
Optional
60 seconds by default.
"VoIP Overview" on page
Remarks
-
