Configure Track-Backup
Center Collaboration
Displaying and
Maintaining Track
Object(s)
n
The Track object to be associated with the policy routing can be a nonexistent
■
one. After you use the track command to create the Track object, the
association takes effect.
For details of policy routing configuration, refer to
■
Policy Routing" on page
You can associate an interface with a Track object, so that the interface can detect
the status of other interfaces based on that of the Track object and change its
backup status accordingly.
If the status of the Track object is positive, then the link where the detected
■
interface resides works normally, and the detecting interface serves as the
backup interface to backup the detected interface.
If the status of the Track object is negative, then the link where the detected
■
interface resides failed, and the detecting interface turns to the main interface
to take on data transmission.
During the configuration, if the Track object is in the invalid state, it indicates
■
that the Track object association does not take effect yet; each interface keeps
its original forwarding state. After the configuration, if the status of the Track
object turns to invalid, the detecting interface becomes the main interface.
Follow these steps to configure the Track-backup center collaboration
To do...
Enter system view
Enter interface view
Configure the association
between the interface and the
Track object
n
You can associate an interface with only one Track object. If you execute the
■
standby track command repeatedly, the latter configuration overwrites the
former.
The Track object to be associated with the interface can be a nonexistent one.
■
After you use the track command to create the Track object, the association
takes effect.
Refer to "Backup Center Configuration" on page 1961
■
backup center.
To do...
Display information about the
specified Track object or all
Track objects

Displaying and Maintaining Track Object(s)

639.
Use the command...
system-view
interface interface-type
interface-number
standby track
track-entry-number
Use the command...
display track
{ track-entry-number | all }
2211
"Configuring IP Unicast
Remarks
-
-
Required
Not configured by default.
for details of the
Remarks
Available in any view
