2224 C 128: IPX C
HAPTER
Configuring the IPX
Forwarding Feature
Configuration
Prerequisite
Configuring IPX
Forwarding Feature
ONFIGURATION
You need configure IPX basic functions before this task.
n
IPX RIP and SAP periodically broadcast updating packets. With the triggered
■
updating feature enabled, updating packets will be sent upon route or service
information changes. Thus, flooding of broadcasts can be avoided.
Split horizon is a way to avoid routing loops, that is, routing information
■
received from an interface is not permitted to be sent from the interface. In
some cases, split horizon must be prohibited to ensure correct routing
information transmission. In addition, split horizon prohibition does not take
effect on point-to-point links.
The type 20 IPX packet is used in NetBIOS. You can either prohibit or permit the
■
forwarding of type 20 broadcast packets based on the actual requirements.
Follow these steps to configure IPX triggered updating feature:
To do...
Enter system view
Enter interface view
Enable the IPX triggered
update feature
Enable the IPX split horizon
feature
Configure the encapsulation
format of IPX frames
Configure an IPX forwarding
delay
Enable the forwarding of type
20 packets
Use the command...
system-view
interface interface-type
interface-number
ipx update-change-only
ipx split-horizon
ipx encapsulation [ dot2 |
dot3 | ethernet-2 | snap ]
ipx tick ticks
ipx netbios-propagation
Remark
-
-
Required
Disabled by default
Optional
Enabled by default
Optional
The default is Ethernet_802.3
(dot3).
Optional
By default, 1 tick for Ethernet
interfaces and VLAN
interfaces, 30 ticks for
asynchronous serial ports, 6
ticks for synchronous ports,
with each tick roughly being
1/18 second.
Required
Disabled by default
