2388 C 138: V FR C
HAPTER O
Configuring Basic
Functions
Configuring DTMF
Transmission
ONFIGURATION
To do...
Enter system view
Enter voice view
Enter voice dial program view dial-program
Create a VoFR entity and
enter VoFR entity view
Configure a match template
for the VoFR entity
Configure an area ID
Configure the DSCP subfield
of the ToS field in IP packets
of the RTP stream carried by
the VoFR entity
Follow these steps to configure the basic functions of the VoFR entity:
To do...
Enter system view
Enter voice view
Enter voice dial program view dial-program
Create a VoFR entity and
enter VoFR entity view
Configure a match template
for the VoFR entity
Configure the codec on basis
of the priority levels
Configure the voice
packetization period for
different codecs
Configure a voice entity
description
Change the management
state of the VoFR entity from
up to down
Follow these steps to configure the DTMF transmission for the VoFR entity:
Use the command...
system-view
voice-setup
entity entity-number vofr
match-template
match-string
area-id string
dscp media dscp-value
Use the command...
system-view
voice-setup
entity entity-number vofr
match-template
match-string
compression { 1st-level |
2nd-level | 3rd-level |
4th-level } { g711alaw |
g711ulaw | g723r53 |
g723r63 | g726r16 | g726r24
| g726r32 | g726r40 | g729a |
g729r8 }
payload-size { g711 | g723 |
g726r16 | g726r24 | g726r32
| g726r40 | g729 }
time-length
description string
shutdown
Remarks
-
-
-
-
Required
By default, no match template
is configured for the VoFR
entity.
Optional
By default, no area ID is
configured.
Optional
EF (101110) by default.
Remarks
-
-
-
-
Required
By default, no match template
is configured for the VoFR
entity.
Optional
By default, the highest codec
is g729r8, the second highest
codec g711alaw, the third
highest codec g711ulaw, and
the lowest g723r53.
Optional
20 milliseconds for a G.711
codec, and 30 milliseconds for
G.723, G.726, and G.729
codecs by default.
Optional
No description by default.
Optional
By default, the management
state of the voice entity is up.
