Setting to Export
Version 5 and Version 8
Packets
Network requirements
Configure NetStream on Router A, set to export NetStream cache entries in
version 5 packets, and configure five aggregation modes. Version 5 packets are
exported to port 5000 of NSC 3.1.1.2/16 and the five aggregation packets (as,
protocol-port, source-prefix, destination-prefix and prefix) are exported to
port 2000, 3000, 4000, 6000 and 7000 respectively.
Establish EBGP neighbor relationships between Router A, Router B, and Router C.
Network diagram
Figure 609 Set to export version 5 and version 8 packets
Eth1/1
Router A 1.1.1 .1/16
AS 100
Eth1/0
11.110.2.1/16
Network
Configuration procedure
1 Configure Router A
# Configure interface Ethernet 1/0 and enable NetStream statistics in both
inbound and outbound directions.
<RouterA> system-view
[RouterA] interface ethernet 1/0
[RouterA-Ethernet1/0] ip address 11.110.2.1 255.255.0.0
[RouterA-Ethernet1/0] ip netstream inbound
[RouterA-Ethernet1/0] ip netstream outbound
[RouterA-Ethernet1/0] quit
# Configure interface Ethernet 1/1.
[RouterA] interface ethernet 1/1
[RouterA-Ethernet1/1] ip address 1.1.1.1 255.255.0.0
[RouterA-Ethernet1/1] quit
# Configure BGP.
[RouterA] bgp 100
[RouterA-bgp] peer 1.1.1.2 as-number 150
[RouterA-bgp] network 11.110.0.0 255.255.0.0
[RouterA-bgp] quit
# Configure NetStream version number and AS number.
[RouterA] ip netstream export version 5 origin-as
# Configure the NetStream cache size.
NetStream Configuration Example
Router B
AS 150
2.1 .1.2/16
Eth1/0 Eth1/1
1.1.1.2/16 2.1.1.1/16
3.1.1.2 /16
Eth1/0
Router C
AS 200
Eth1 /1
3.1.1 .1/16
NSC
