Displaying and

Maintaining PoE

PoE Configuration

The support for the display poe pse pse pse-id interface and display poe pse

pse-id interface power commands varies with devices.

Display the mapping between ID,

module, and slot of all PSEs.

Display the power state and information

of the specified PoE interface

Display the power information of a PoE

interface(s)

Display the power information of the

PoE power and all PSEs

Display the information of PSE

Display information of the PoE power

Display all information of the

configurations and applications of the

PoE configuration file

Display all information of the

configurations and applications of the

PoE configuration file applied to the

specified PoE interface

Network requirements

The device is equipped with two PoE-supporting cards, which are inserted in

Slot 3 and Slot 5 respectively. The PSE IDs are 4 and 6.

Allocate 400 watts to PSE 4, provided the default maximum power to PSE in

PSE 6 can meet the requirements.

GigabitEthernet3/1 and GigabitEthernet3/2 are connected to IP telephones.

GigabitEthernet5/1 and GigabitEthernet5/2 are connected to access point (AP)

The power priority of GigabitEthernet3/2 is critical.

The power of the AP device connected to GigabitEthernet5/1 does not exceed

9,000 milliwatts.
