D-Link DI-1750 Reference Manual page 236

area area-id authentication simple
area area-id
message-digest
area area-id stub [no-summary]
area area-id default-cost cost
Take the first command for an example.：
In the prompt Select 0 option ，prompt is as below:
(00)<0-4294967295>
(01)A.B.C.D
Please Input the code of command to be excute(0-1): 0
input 0，prompt is as below:
Please input a digital number:Please input a string:
input area-id value ，then prompt is as below:
(00)authentication
(01)default-cost
(02)nssa
......
Please Input the code of command to be excute(0-4): 0
input 0，Select authentication option ，prompt is as below:
(00)message-digest
(01)simple
Please Input the code of command to be excute(0-1): 1
input 1，Select simple option and confirm it.
6.11.10 Configuring Route Summarization In OSPF Area
This feature causes a single summary route to be advertised to other areas by an ABR. In OSPF, an
ABR will advertise networks in one area into another area. If the network numbers in an area are
assigned in a way such that they are contiguous, you can configure the ABR to advertise a summary
route that covers all the individual networks within the area that fall into the specified range.
To specify an address range, use the following command in router configuration mode:
area area-id range address mask
In the prompt Select 0 option ，prompt is as below:
(00)<0-4294967295>
(01)A.B.C.D
Please Input the code of command to be excute(0-1): 0
input 0，prompt is as below:
Please input a digital number:Please input a string:
input area-id value ，then prompt is as below:
(00)authentication
(01)default-cost
(02)nssa
(03)range
......
Please Input the code of command to be excute(0-4): 3
input 3，Select range option ，prompt is as below:
(00)A.B.C.D
Please Input the code of command to be excute(0-0): 0
Command
authentication
OSPF area ID as a decimal value
OSPF area ID in IP address format
Enable authentication
Set the summary default-cost of a NSSA/Stub area
Specify a NSSA area
Use message-digest authentication
Use simple authentication
Command
OSPF area ID as a decimal value
OSPF area ID in IP address format
Enable authentication
Set the summary default-cost of a NSSA/Stub area
Specify a NSSA area
Summarize LS_SUM_NET (border routers only)
IP address for match network
Model Name
Function
Enable authentication for an OSPF area.
Enable MD5 authentication for an OSPF area.
Define an area to be a stub area.
Assign a specific cost to the default summary route used
for the stub area.
Function
Specify an address range for route of summarization.
- 234 -
