Field-Replaceable Units - Oracle X5-2L Service Manual

About System Components
CRU Description
■ Up to eight 2.5-inch hot-pluggable SAS HDDs or
SSDs, with optional support for up to four PCIe-
based NVMe SSDs
Fan modules Four fan modules for cooling the server components.
PCIe cards Optional add-on cards that can expand the functionality
of the server.
Power supply unit Two fully redundant AC-powered power supplies.
(PSU)
Related Information
"Field-Replaceable Units" on page 22
■
"Illustrated Parts Breakdown" on page 19
■
"Servicing CRUs That Do Not Require Server Power-Off"
■
"Servicing CRUs That Require Server Power-Off"
■

Field-Replaceable Units

The following table lists the field-replaceable units (FRUs) in the server and directs you to the
replacement instructions.
FRU Description
Processor and The processor that carries out the instructions of the
heatsink system.
Disk backplanes Provide power and communications connectors for
storage drives.
SAS cables Provide signals between the front disk backplane and
the Oracle Storage 12 Gb/s SAS PCIe RAID HBA,
and from the front disk backplane to the rear disk
backplane.
NVMe cables Provide signals between the Oracle PCIe NVMe switch
card and the disk backplane.
Oracle Storage 12 Located in PCIe slot 6, the Oracle Storage 12 Gb/s SAS
Gb/s SAS PCIe PCIe RAID HBA manages SAS storage drives.
RAID HBA
DVD drive Optional DVD drive on configurations with eight 2.5-
inch drives.
Front LED/USB Contain the push-button circuitry and LEDs that are
indicator modules displayed on the bezel of the chassis.
Motherboard Provides connectors for the DIMMs, processors, PCIe
assembly risers, and other components.
22 Oracle Server X5-2L Service Manual • May 2015
Replacement Instructions
"Servicing Fan Modules (CRU)" on page 89
"Servicing PCIe Cards (CRU)" on page 115
"Servicing Power Supplies (CRU)" on page 93
Replacement Instructions
"Servicing Processors (FRU)" on page 129
"Servicing the Front and Rear Storage Drive Backplanes
(FRU)" on page 146
"Servicing SAS Cables (FRU)" on page 167
"Servicing NVMe Cables (FRU)" on page 174
"Servicing the Oracle Storage 12 Gb/s SAS PCIe RAID
HBA Card (FRU)" on page 180
"Servicing the DVD Drive (FRU)" on page 187
"Servicing the Front LED/USB Indicator Modules
(FRU)" on page 193
"Servicing the Motherboard Assembly
(FRU)" on page 209
