Oracle X5-2L Service Manual page 283

Setup Options
Connection Retry Count
Connection Establishing
Timeout
Configure ISID
Enable DHCP
Initiator IP Address
Initiator Subnet Mask
Gateway
Target Name
Target IP address
Target Port
Boot LUN
Authentication Type
CHAP Type
CHAP Name
Options
0 to 16
NA
Derived from the MAC address
Disabled/Enabled
NA
NA
NA
NA
0.0.0.0
CHAP/None
One Way/Mutual
NA
Defaults
0
1,000
The default value is derived
from the Mac Address
Disabled
0.0.0.0
0.0.0.0
0.0.0.0
NA
None
3260
0
CHAP
One Way
None
BIOS Setup Utility Menu Options
BIOS Advanced Menu Selections
Description
to connect to the iSCSI target
using the IPv4 stack. If this fails,
then the iSCSI driver attempt to
connect using the IPv6 stack.
The count range is 0 to 16. If set
to 0, there are no retries.
The timeout value in
milliseconds. The minimum
value is 100 milliseconds and
the maximum is 20 seconds.
The OUI-format ISID is 6 bytes.
The default value is derived
from the MAC address. Only the
last 3 bytes are configurable.
Example: Update
0ABBCCDDEEFF to
0ABBCCF07901 by inputting
F07901
Enable or disable DHCP
Use to set initiator IP address in
dotted-decimal notation.
Use to set initiator subnet mask
IP address in dotted-decimal
notation.
Use to set initiator gateway
IP address in dotted-decimal
notation.
The worldwide unique name of
the target. Only IQN format is
accepted.
Use to set target IP address in
dotted-decimal notation.
Use to change target port
number.
Use to set the hexadecimal
representation of the boot logical
unit number (LUN).
Example: 4752-3A4F-6b7e-
2F99
Define the Challenge-
Handshake Authentication
Protocol (CHAP). Available
settings are CHAP, Kerberos,
and None.
Use to set CHAP type to either
One Way or Mutual.
Use to set CHAP name.
283
