See "Reconnect Power and Data Cables" on page 233
Server" on page
Related Information
"Server System-Level Status Indicators" on page 31
■
"Remove the Left LED Indicator Module" on page 193
■

Remove the Right LED/USB Indicator Module

1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See "Powering Down the Server" on page
b. Extend the server into the maintenance position.
See "Extend the Server to the Maintenance Position" on page
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
c.
chassis.
See "Take Antistatic Measures" on page
d. Remove the server top cover.
See "Remove the Server Top Cover" on page
Depending on your server's storage drive configuration, do one of the following:
2.
If your server is configured with twelve 3.5-inch storage drives or twenty-
■
four 2.5-inch storage drives, perform the following procedures.
a. Remove the server fan assembly door.
See "Remove the Fan Assembly Door From the Server" on page
Remove the four remaining No. 2 Phillips screws (two on each side of
b.
the chassis) that secure the disk cage assembly to the server chassis.
233. Verify that the power supply AC OK LED is lit.
64.
Remove the Right LED/USB Indicator Module
and "Power On the
55.
61.
64.
65.
Servicing FRUs 201
