Oracle X5-2L Service Manual page 169

See "Remove the Disk Cage Cover From the Server" on page
2. Disconnect the SAS cables.
a. (Optional) To disconnect the SAS cables between the rear storage drive
backplane and front storage drive backplane, press each latch, and then pull
out to disengage the cable from each SAS connector [1].
b. To disconnect the SAS cables between the Oracle Storage 12 Gb/s SAS
PCIe RAID HBA card in PCIe slot 6 and the front storage drive backplane,
press each latch, and then pull out to disengage the cable from each SAS
connector [1 and 2].
See also "Remove the Oracle Storage 12 Gb/s SAS PCIe RAID HBA
Card" on page
The following figure shows SAS cables being removed from the twenty-four
Note -
drive system configuration. If you are removing SAS cables from an eight-drive system
configuration, your front disk backplane SAS connector locations will be different. In addition,
the chassis mid-wall is removed in the illustration to clearly show the SAS cable connections.
180.
Remove SAS Storage Drive Cables
67.
Servicing FRUs 169
