Take Antistatic Measures

Take Antistatic Measures
Prepare an antistatic surface on which to set parts during removal and
1.
installation.
Place electrostatic discharge (ESD-sensitive components on an antistatic mat. The following
items can be used as an antistatic mat:
An antistatic bag used to wrap a replacement part
■
An Oracle ESD mat (orderable item)
■
A disposable ESD mat (shipped with some replacement parts or optional system
■
components)
Attach an antistatic wrist strap.
2.
When servicing or removing server components, attach an antistatic strap to your wrist and then
to a metal area on the chassis. Then perform procedures for servicing the server.
Note -
antistatic wrist straps are included with options and components.
Related Information
"Extend the Server to the Maintenance Position" on page 61
■
"Remove the Server From the Rack" on page 63
■
"Remove the Server Top Cover" on page 64
■
"Remove the Fan Assembly Door From the Server" on page 65
■
"Remove Antistatic Measures" on page 230
■

Remove the Server Top Cover

Caution -
only will the server host shut down, but also this condition will be flagged as a system fault
(that is, the fault LEDs will light).
Note -
Ensure that AC power cords are disconnected from the server power supplies.
1.
2. Unlatch the top cover [1].
Press the green release button on the top of the server cover.
64 Oracle Server X5-2L Service Manual • May 2015
An antistatic wrist strap is not included in the Accessory Kit for the server. However,
If you remove the top cover without first removing the AC power cords, then not
Servicing some components requires that the top cover be removed.
