Remove the Motherboard Assembly
See
Attach an antistatic wrist strap to your wrist, and then to a metal area of the
c.
chassis.
See
Remove the server top cover.
d.
See
Remove the Oracle Storage 12 Gb/s SAS PCIe RAID HBA card and its associated
2.
super capacitor.
See "Remove the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card" on page
Remove the air baffle.
3.
Remove the air baffle by lifting the baffle up and out of the server.
Remove the following reusable components:
4.
Caution -
with the slot numbers from which they were removed (PS0, PS1). This is required because the
power supplies must be reinstalled into the slots from which they were removed; otherwise, the
server key identity properties (KIP) data might be lost. When a server requires service, the KIP
is used by Oracle to verify that the warranty on the server has not expired. For more information
on KIP, see
Fan modules
■
See
SAS storage drive cables
■
See
NVMe cables (if present)
■
See
PCIe cards
■
See
Power supplies
■
See
5. If the server has a DVD drive, disconnect the DVD drive cable from the
motherboard SATA connector.
To remove the DVD drive cable, carefully guide it through the chassis mid-wall and place it on
top of the disk cage so that it is away from the motherboard. You do not need to disconnect the
DVD drive cable from the DVD drive.
210 Oracle Server X5-2L Service Manual • May 2015
"Extend the Server to the Maintenance Position" on page
"Take Antistatic Measures" on page
"Remove the Server Top Cover" on page
During the motherboard removal procedure, it is important to label power supplies
"FRU Key Identity Properties (KIP) Automated Update" on page
"Remove a Fan Module" on page
"Remove SAS Storage Drive Cables" on page
"Remove NVMe Cables" on page
"Remove a PCIe Card" on page
"Remove a Power Supply" on page
64.
64.
89.
168.
175.
117.
94.
61.
180.
53.
