Install SAS Storage Drive Cables
FIGURE 56
b.
(Optional) Install the cables between the front storage drive backplane and
the rear storage drive backplane [2].
Note -
installing SAS cables between the rear storage drive backplane and front storage drive
backplane, you first must remove the chassis mid-wall. For instructions, see
the Motherboard Assembly" on page
172
Oracle Server X5-2L Service Manual • May 2015
Installing SAS Storage Drive Cables
SAS cable connectors do not fit through the right-side chassis mid-wall. If you are
219.
