Remove an HDD or SSD Storage Drive
FIGURE 15
Figure Legend
1
Pressing the latch release button.
2
Opening the latch.
Caution -
damage the latch.
5.
Grasp the latch and pull the drive out of the drive slot.
76
Oracle Server X5-2L Service Manual • May 2015
Opening the Drive Latch
The latch is not an ejector. Do not open the latch too far to the right. Doing so can
