Oracle X5-2L Service Manual page 138

Remove a Processor
b. Properly position the tool over the processor socket and lower it into place
over the processor socket [2].
To properly position the tool over the processor socket, rotate the tool until the green
triangle on the side of the tool is facing the front of the server and it is over the left side of
the processor socket when viewing the server from the front.
c. Press the release lever on the processor tool to release the center button
and engage the processor [3].
An audible click indicates that the processor is engaged.
Grasp the tool by the sides and remove it from the server [4].
d.
Turn the tool upside down and verify that it contains the processor [5].
e.
f. While holding the processor tool upside down, press the center button on
the tool to release the processor [5].
g. Carefully grasp the processor by the front and back edges, lift it out of the
tool and place it with the circuit side down (the installed orientation) into an
antistatic container [6].
h. Carefully clean the thermal grease off the top of the processor.
Caution -
replacement tool. If you are removing a processor with 12 or more cores, you must use the
pink color-coded processor removal and replacement tool. For information on how to select the
correct processor removal and replacement tool, see
and Replacement Tool" on page
138 Oracle Server X5-2L Service Manual • May 2015
The following figure shows the green color-coded processor removal and
130.
"Selecting the Correct Processor Removal
