About Controls and Connectors

■
■
■
■
Two hot-pluggable, redundant 1000W power supplies.
■
An on-board Oracle Integrated Lights Out Manager (Oracle ILOM) service processor (SP)
■
based on the Emulex Pilot 3 chip.
The optional Oracle System Assistant server setup tool, which is embedded on a preinstalled
■
USB flash drive.
About Controls and Connectors
The following sections describe the controls, indicators, connectors, and drives located on the
front and rear panels.
"Front Panel Components on Twelve Drive Systems" on page 16
■
"Front Panel Components on Twenty-Four Drive Systems" on page 17
■
"Rear Panel Components and Cable Connections" on page 18
■
Related Information
"About System Components" on page 19
■
"Illustrated Parts Breakdown" on page 19
■
"Troubleshooting Using the Server Front and Rear Panel Status Indicators " on page 30
■

Front Panel Components on Eight Drive Systems

Note -
drives and twenty-four drives do not contain a DVD drive.
14 Oracle Server X5-2L Service Manual • May 2015
Up to twelve 3.5-inch hot-pluggable SAS HDDs
Up to twenty-four 2.5-inch hot-pluggable SAS HDDs or SSDs, with optional support for
up to four PCIe-based NVMe SSDs
Up to eight 2.5-inch hot-pluggable SAS HDDs or SSDs, with optional support for a
SATA DVD and up to four PCIe-based NVMe SSDs
(Optional) Up to two rear-mounted 2.5-inch SAS storage drives in the twelve 3.5-inch
storage drive and twenty-four 2.5-inch storage drive configurations
Systems with eight drives can contain an optional DVD drive. Systems with twelve
